About

Description

The DM-TX-4K-100-C-1G provides a simple, cost-effective interface solution for a single HDMI, DVI, or Dual-Mode DisplayPort source as part of a complete Crestron® DigitalMedia™ system. It functions as a DM 8G+® transmitter and control interface, providing a single HDMI® input along with RS-232 and IR control ports.[1] In addition to DM 8G+, it is also compatible with HDBaseT®, allowing it to be connected directly to an HDBaseT certified receiver or display device.

Its 1-gang mountable design allows the DM-TX-4K-100-C-1G to be flush mounted in a wall or presentation lectern. It can also be mounted beneath a table or attached to a suitable flat surface using the mounting bracket provided. It connects to the head end or display location using a single CAT type twisted pair cable.[2] Standard gang-box mounting (3-1/2" deep) allows for installation adjacent to an Ethernet jack (Crestron MP-WP183 or equivalent) for a total connectivity solution.

Key Features:

  • Cost-effective DigitalMedia 8G+® transmitter
  • Connects to a DM® switcher or receiver over a single CAT type twisted pair cable [2]
  • HDBaseT® Certified — Enables direct connection to other HDBaseT certified equipment
  • Provides one HDMI® input [4]
  • Also supports DVI and Dual-Mode DisplayPort sources [4]
  • Handles video resolutions up to 4K and Ultra HD
  • Handles 3D video and Deep Color
  • Handles Dolby® TrueHD, Dolby Atmos®, DTS-HD®, and uncompressed 7.1 linear PCM audio
  • HDCP 2.2 compliant
  • Supports cable lengths up to 330 ft (100 m) for all resolutions up to UHD and 4K using DM Ultra cable [2]
  • Supports cable lengths up to 330 ft (100 m) for 1080p, WUXGA, and 2K using DM 8G® cable or CAT5e [2]
  • Supports cable lengths up to 230 ft (70 m) for UHD and 4K using DM 8G cable, or 165 ft (50 m) using CAT5e [2]
  • Enables device control via CEC, IR, and RS-232 [1,7]
  • Powered via the DM connection or local power pack (included) [5,6]
  • 1-gang wall box mount design (3-1/2" deep)
  • Surface mount bracket included
  • Available in white or black finish


Benefits of Crestron DM-TX-4K-100-C-1G-B-T  Wall Plate 4K DigitalMedia 8G+® Transmitter 100, Black Textured:

4K Ultra HD
Crestron DigitalMedia continues to advance the standard for digital AV signal distribution, delivering the world’s first end-to-end 4K system solution. The DM-TX-4K-100-C-1G features the latest DM 8G+ technology, providing support for the transport of 4K and Ultra HD video signals. Support for 4K video also ensures support for the latest generation of computers and monitors with native resolutions beyond 1080p and WUXGA.

HDBaseT® Certified
Crestron DigitalMedia 8G+ technology is designed using HDBaseT Alliance specifications, ensuring interoperability with other HDBaseT certified products. Via its DM 8G+ output, the DM-TX-4K-100-C-1G can be connected directly to an HDBaseT compliant device without requiring a DM receiver.

Multimedia Computer/AV Interface

A single HDMI digital AV input port is provided on the DM-TX-4K-100-C-1G for connection of a laptop computer, mobile device, or other AV source. The HDMI input can also handle DVI and Dual-Mode DisplayPort signals using an appropriate adapter or interface cable.[4]

A single CAT type cable connects the DM-TX-4K-100-C-1G to a DM switcher or receiver, or to an HDBaseT device, transporting video, audio, control, and power signals all through one simple RJ45 connection.[2,5,6] Used with a single DM 8G+ Receiver/Room Controller, the DM-TX-4K-100-C-1G affords a simple solution for extending a computer or AV signal to a single display. As part of a larger system using a DM-MD series switcher, multiple DM-TX-4K-100-C-1Gs may be installed to enable the distribution of several sources at different locations to feed multiple displays throughout any room or larger facility.

LAN Connectivity

Along with high-definition AV and control, DigitalMedia also integrates high-speed Ethernet networking for a total signal distribution solution. The DM-RMC-4KZ-100-C includes a 10/100 Ethernet port, which can be used to provide a convenient LAN connection for a local network device.

Embedded Device Control

The DM-TX-4K-100-C-1G includes built-in RS-232 and IR control ports to allow for programmable control of the connected source device (via a control system).[1] Additional control capability is afforded by harnessing the CEC (Consumer Electronics Control) signal embedded in HDMI. Through its connection to the control system, the DM-TX-4K-100-C-1G provides a gateway for controlling the source right through its HDMI connection, potentially eliminating the need for a dedicated serial cable or IR emitter.

      Where to buy?
      Buy the Crestron DM-TX-4K-100-C-1G-B-T  Wall Plate 4K DigitalMedia 8G+® Transmitter 100, Black Textured online at the best price in Mumbai, Delhi, Bangalore, Chennai and all across India. Enjoy expert, prompt and courteous customer service from the Ooberpad team. We will help you choose better and give you all the support you need to take the right buying decision in India.
