Denon Professional DN-312X 12-Channel Line Mixer with Priority

Need pricing? Get in Touch...

Ooberpad brings to you the power-packed Denon Professional DN-312X 12-Channel Line Mixer with Priority. The DN-312X is a 1U rack-mounted 12-channel mixer that can solve countless audio challenges. It is feature-packed with 6 mic/line combination inputs (HDHQ™ Denon-Marantz proprietary mic pre’s) each with switchable phantom power and 6 additional line-level inputs. It has balanced XLR outputs, a 1/4-inch (6.3mm) mono output that can be used to connect the DN-312X to a remote mixer, a pair of RCA stereo outputs to connect to a remote recording device, and 1/4-inch (6.3mm) mic monitoring port that can be used to monitor the mics’ signals. The DN-312X provides individual level control for all inputs in addition to level control for the mono output port and a master level control. Rounding off the feature set, It has a 3-level equalizer and a controlled priority for Mic/Line 1. It can be powered from standard AC or a 24V DC power source, inviting it to be used in a diverse set of applications; whether it is a classroom to a tour bus.

Warranty

1-year manufacturer's warranty

Key Features:

  • 6 HDHQ™ Combination inputs with MIC, Phantom and Line selector switches
  • 6 mono (3 stereo) RCA Inputs
  • Mic monitor 1/4” output for private listening of all mic inputs
  • Balanced XLR line outputs
  • Mono 1/4” line output can be used to feed audio to external recording device
  • AC or 24V DC power inputs
  • Mic 1 Priority Control
  • Master and Individual level controls
  • 1U rack mountable

Where to buy?
Buy Denon Professional DN-312X 12-Channel Line Mixer with Priority online at the best price in Mumbai, Delhi, Bangalore, Chennai and all across India. Enjoy expert, prompt and courteous customer service from the Ooberpad team. We will help you choose better and give you all the support you need to take the right buying decision in India.

Technical Specifications of Denon Professional DN-312X 12-Channel Line Mixer with Priority:

Brand & Model # Denon Pro DN-312X
Input Channels
  • Microphone Input: 6 Balanced XLR Connectors (Channels 1–6)
  • Frequency Response: 20 Hz - 22 kHz
  • THD+N: < 0.03% @ 1 kHz
  • Sensitivity: -40 dBu
  • Maximum Input: -19 dBu
  • Maximum Voltage Gain:
    60 dB (Mic Input to Line Out, Mic Out & Mono Out)
    50 dB (Mic Input to Rec Out)
  • Signal-to-Noise Ratio: > 103 dB
  • Phantom Power: 18–21 V, switch control
  • Line Inputs: 6 Balanced XLR Connectors (Channels 1–6)
  • Frequency Response:
    20 Hz - 22 kHz
    20 Hz - 22 kHz
  • THD+N:< 0.03% @ 1 kHz
  • Sensitivity: 0 dBu
  • Maximum Input:
    +21 dBu
    +21 dBu
  • Maximum Voltage Gain:
    20 dB (Mic Input to Line Out, Mic Out & Mono Out)
    10 dB (Mic Input to Rec Out)
    10 dB (Line Input to Line Out)
    0 dB (Line Input to Rec Out)
    4 dB (Line Input to Mono Out)
  • Signal-to-Noise Ratio: > 103 dB
Stereo Balanced RCA Connectors (Channels 7/8-11/12)
  • THD+N: < 0.03% @ 1 kHz
  • Sensitivity: +10 dBu
  • Signal-to-Noise Ratio: > 103 dB
  • Impedance: Mic/Line Input: 1.4 kΩ
  • Line Input: > 10 kΩ
  • All Outputs: 120 Ω
Equalizer
  • High: +15 dB @ 12 kHz
  • Mid: +12 dB @ 2.5 kHz
  • Low: +15 dB @ 80 Hz
Crosstalk
  • Adjacent Inputs:
  • < -70 dB @ 1 kHz (Channels 1–6)
    < -68 dB @ 1 kHz (Channels 7/8–11/12)
  • Input to Output: < -82 dB @ 1 kHz
Main MixOutput
  • Line Output: 0 dBu (+2 dBu), balanced
  • Mic Output, Mono Output: 0 dBu (+2 dBu), unbalanced
  • Maximum Output: +21 dBu balanced/unbalanced, 1/4” (6.35 mm) jacks
  • Noise (Bus): < -83 dB @ 20 Hz – 22 kHz
General
  • Power connection: IEC
  • Input Voltage: 100V~, 110-120V~, 50/60Hz; 220-240V~, 50/60Hz or DC24V
  • Dimensions (width x depth x height): 19.0” x 7.7” x 1.7” (483 x 195 x 44 mm)
  • Weight: 6.4 lbs (2.9 kg)
Included in the Box
  • DN-312X mixer
  • IEC Cable
  • User Guide
  • Safety and Warranty Manual


PN: All Pre-order/On-Order/Special-Color takes minimum 4-6 weeks to arrange from brand. Please speak with Customer Support Representative incase of any queries.
