Emotiva XPA-DR1 Differential Reference™ Monoblock Power Amplifier

Sold out
₹ 175,000.00
No Cost EMI: Avail No Cost EMI on Bajaj Finserve and select Credit Cards for orders above ₹3000 Details

EMI Guide


EMI for Rs.

Below EMI options can be availed while making payment. To avail EMI continue to check out and chose the Credit Card option for payment.

Ooberpad brings you the Emotiva XPA-DR1 Differential Reference™ Monoblock Power Amplifier for home theatre systems. The XPA-DR1 is a true monoblock power amplifier, and features a single Differential Reference Amplifier Module, in a true monoblock configuration, powered by its own dedicated 3 kW switch mode power supply. The XPA-DR1 provides massive power, superb dynamics, incredible resolution, and absolute control. If you’re looking for the very best sound quality, with virtually endless reserves of power against a jet black noise floor, this is the amplifier for you. The XPA-DR1 delivers 650 watts RMS into 8 Ohms, and 1000 watts RMS (that’s 1 kW) into 4 Ohms, with less than 0.1% THD.


5-year manufacturer's warranty

Key Features:

  • 650 watts RMS into 8 Ohms, and 1000 watts RMS into 4 Ohms, with less than 0.1% THD
  • Modular, high-powered, fully-differential, low distortion amplifier design with traditional Class A/B output stage
  • Optimized Soft-Switch Class H™ power supply topology delivers improved efficiency without compromising audio performance
  • Switched Mode Power Supply (SMPS) offers all of the performance of a traditional linear power supply, with improved efficiency and reliability, and reduced overall weight
  • Heavy steel 4RU chassis with a milled aluminum faceplate
  • Choice of balanced or unbalanced input for each channel, independently controlled by reliable metal toggle switches
  • Solid machined gold-plated RCA input connectors provide a reliable connection with a wide variety of audio interconnects
  • Gold plated five-way speaker binding posts with clear shields allow the use of a wide range of speaker cables with bare wires, lugs, or banana plugs
  • Remote trigger input and output
  • Designed, assembled, and tested in the U.S.A

        Benefits of Emotiva XPA-DR1 Differential Reference™ Monoblock Power Amplifier:

        The Power Supply: The Foundation Of A Great Amplifier
        The Power Supply: The Foundation Of A Great Amplifier

        In the amplifier design, everything starts with the power supply. The XPA-DR1 features a custom-configured version of our high-current switch-mode power supply (SMPS) - a lightweight, powerful, intelligent design capable of delivering over 3 kW of continuous power with absolute reliability and extremely high efficiency. Emotiva's cutting edge SMPS offers the dynamic attributes of a classic transformer-based design with none of the drawbacks. Like the best transformer-based power supplies, the SMPS delivers plenty of continuous power to enable our amplifier modules to live up to their full performance potential, and plenty of dynamic power to ensure that musical peaks will never be compressed or limited. However, compared to transformer-based designs, the SMPS is lighter and more efficient; it’s also fully regulated, which ensures optimum performance under a wider range of load conditions.

        The Latest In A Long Line Of Great Amplifiers
        The Latest In A Long Line Of Great Amplifiers

        The Differential Reference Amplifier Modules that is used in XPA-DR amplifiers use the same basic circuit topology as the legendary XPR series amplifiers. A unique differential input stage, with a cross-linked current source, drives a balanced voltage amplification stage, and this advanced input circuitry delivers an incredibly accurate and pure audio signal to the complementary, fully discrete output stage. A pair of these modules work together in perfect synergy to power a single channel of one of our new fully balanced, fully differential, XPA-DR amplifiers. Together they deliver a holistic, natural, and powerful listening experience.

        Class A/B Sound Quality Meets Optimized Class H Efficiency

        The Differential Reference™ Module in the XPA-DR1 utilizes a matched pair of amplifier modules, each of which features fully analog Class A/B output stage, and highly regarded Soft-Switch™ Class H power supply topology, which increases their efficiency significantly without compromising the audio performance you’d expect from an Emotiva amplifier. The output stage in each operates on a lower supply voltage at low power levels to minimize quiescent power consumption and standby power losses, instantly switching to a higher voltage rail when needed to ensure the signal passes cleanly and without clipping.

        Modular Construction
        Modular Construction

        Each XPA-DR Differential Reference Monoblock Power Amplifier is comprised of a heavy-duty chassis, which houses our massively overdesigned, fully regulated, 3 kW switch mode power supply, and up to three Differential Reference™ Amplifier Modules. The front panel display and protection system are designed to work with the maximum number of channels, and so need not be updated when the XPA-DR is expanded; on the rear panel, slots not occupied by amplifier modules will be covered with protective cover panels. (Because the XPA-DR1 is configured with a single Differential Reference Module, up to two additional modules can be added later).

        Where to buy?
        Buy the Emotiva XPA-DR1 Differential Reference™ Monoblock Power Amplifier online at the best price in Mumbai, Delhi, Bangalore, Chennai and all across India. Enjoy expert, prompt and courteous customer service from the Ooberpad team. We will help you choose better and give you all the support you need to take the right buying decision in India.

        Technical Specifications of Emotiva XPA-DR1 Differential Reference™ Monoblock Power Amplifier:

        Brand & Model Emotiva XPA-DR1 Differential Reference™ Monoblock Power Amplifier
        Audio Specifications (High-Powered Single Channel Modules)
        Power Output:
        • 650 watts RMS into 8 Ohms at <0.1% THD.
        • 1000 watts RMS into 4 Ohms at <0.1% THD.
        • Power Bandwidth (at rated power; 8 Ohm load): 20 Hz to 20 kHz (+ / – 0.1 dB).
        • Broad Band Frequency Response: 20 Hz to 50 kHz +0/-2 dB.
        • THD + noise: < 0.008%; at 100 watts RMS; 1 kHz; 8 Ohms.
        • Signal to Noise Ratio (8 Ohm load):
        • > 122 dB; ref FTC rated power; unbalanced input (A-weighted).
        • > 96 dB; ref 1 watt; unbalanced input (A-weighted).
        • Minimum Recommended Load Impedance (per channel): 4 Ohms
        • (which equals one 4 Ohm load or two paralleled 8 Ohm loads).
        • Damping Factor (8 Ohm load): > 500.
        • Input Sensitivity (for rated power; 8 Ohm load): 2.4 V.
        • Gain: 29 dB.
        • Input Impedance:
        • 33 kOhms (balanced).
        • 23.5 kOhms (unbalanced).
            Power Requirements

            • Between 100 VAC and 250 VAC @ 50 / 60 Hz (automatically detected).
            • Front Panel Controls and Indicators
            • Standby: push button (halo ring changes color to indicate Standby or On).
            • Status LEDs: one per channel; blue.
            • Status LEDs change to red to indicate a fault condition.
              Input and Output Connections
              Input Connections:
              • Unbalanced (RCA); balanced (XLR); one each, user selectable.
              • Speaker Output Connections: Audiophile grade, gold plated, 5-way binding posts.
              • Trigger:
              • Trigger Input: 5 – 12 V (AC or DC); <10 mA input current required.
              • Trigger Output: 12 VDC; can drive any load up to 120 mA.
                Rear Panel Controls

                • AC Power switch: rocker switch (switches AC main power)
                • Status LEDs switch: disables front panel Status LEDs and dims Standby button halo
                • Input selector switches (one per channel):
                • metal toggle switches; select between balanced and unbalanced inputs
                • Circuit Breaker: press button to reset circuit breaker
                  Protection The XPA-DR1 is protected against excessive operating temperature, shorted speaker connections, ground faults, and other common fault conditions
                  Dimensions (W x H x D) in inches
                  17” wide x 8” high x 19” deep (unboxed; including feet)
                  17” wide x 7” high x 19” deep (unboxed; without feet)
                  24-1/2” wide x 12” high x 24-3/4” deep (boxed)
                  35.5 lbs (unboxed)
                  40.5 lbs (boxed)
