About

Description


Ooberpad announces the availability of the feature-packed Denon PMA-1700NE Integrated Amplifier with USB-DAC - an ultra-high-fidelity integrated stereo amplifier with USB-DAC for High-res Audio. The 1600NE series has been built by both veteran engineers and talented young engineers who have inherited the Denon technologies and expertise that have been cultivated over many years and decades.

With its robust built-quality, unique Denon technologies and functionally sophisticated connectivity, the PMA-1700NE truly is a masterpiece of sound technology. Featuring advanced ultra-high current single push-pull circuit power, Advanced AL32 Processing Plus, and MM/MC phono equalizer, the Denon PMA-1700NE integrated amplifier delivers extraordinary sound quality with precise detail.

Warranty

1-year manufacturer's warranty

Key Features:

    • Engineered with premium Denon technologies, this amplifier drives two channels at 140W
    • Advanced AL32 Processing Plus delivers the richly detailed sound the artist intended
    • Wide bandwidth sound from deep bass to detailed highs
    • DAC Master Clock Design for jitter-free audio reproduction
    • Digital isolator to eliminate high-frequency computer noise on the USB-B or digital inputs
    • FL display for source and sample rate indication
    • Analog AMP Mode switching off digital audio circuitry and display
    • Direct Mechanical Ground Construction to minimize unwanted vibration
    • Main transformer with separate power supplies for analogue and digital circuits for maximum audio signal purity
    • With more than 110 years of audio excellence, Denon products are built to last

        Benefits of Denon PMA-1700NE Integrated Amplifier with USB-DAC:

        Advanced AL32 Processing Plus

        Advanced Ultra High Current MOS Single Push-Pull Circuit

        Advanced AL32 Processing Plus supports digital audio sources up to high resolution of 384-kHz/32-bit. The algorithms restore information that was lost during the digital recording to ensure detailed playback.

        High-power 140W integrated amplifier
        High-power 140W integrated amplifier

        Drive your loudspeakers with 140 Watts of power per-channel into 4 Ohms. This integrated amplifier offers compatibility with the widest range of speaker types and impedances for operational stability.

        High-precision electrical controls
        High-precision electrical controls

        The PMA-1700NE embraces electrical volume, balance, and tone controls while preserving the analogue feeling of operation. The unique mechanism offers smooth, linear control. A Source Direct function passes by all tone control for purest audio.

        USB-DAC supporting 11.2-MHz DSD and 384-kHz/32-bit PCM

        USB-DAC supporting 11.2-MHz DSD and 384-kHz/32-bit PCM

        PMA-1700NE provides USB-DAC function that supports high resolution audio signals up to 11.2-MHz DSD and 384-kHz/32-bit PCM. These digital signals with suppressed jitter will get passed on to the high quality DAC for an optimal D/A conversion with highest precision.

        Where to buy?
        Buy the Denon PMA-1700NE Integrated Amplifier with USB-DAC online at the best price in Mumbai, Delhi, Bangalore, Chennai and all across India. Enjoy expert, prompt and courteous customer service from the Ooberpad team. We will help you choose better and give you support to help you take the right buying decision in India.

        Technical Specifications of Denon PMA-1700NE Integrated Amplifier with USB-DAC:

        Brand & Model # Denon PMA-1700NE Amplifier
        General
        • Unit (W x D x H) 434 x 410 x 135mm
          17.1 x 16.1 x 5.3in
        • Cabinet Size (W x D x H) 434 x 374 x 135mm
          17.1 x 14.7 x 5.3in
        • Net weight 17.6kg / 38.8lb
        • Front (Center): Panel Aluminum
        • Side cover: SECC with 4 straight emboss
        • Side screw: SP: Nickel / BK: Black
        • Rear Panel: SECC t1.0mm
        • Chassis Material: SECC t1.2mm
        • Bottom Layer Single
        • Volume Knob: Aluminum
        • Input Selector: Aluminum
        • Bass/Treble/Balance/ Phono Sel knobs: Aluminum
        • Power button: Aluminum
        • Other knob/button (LOUDNESS, SOURCE DIRECT etc): Mold (Source Direct,Analog Mode,MM/MC)
        • Foot: ABS resin with rigid rib
          w/Hot stamp (H : 20mm)
        • Heatsink for Power Amplifier: Extruded Aluminum
        Power Amplifier Rated Output
        • 70W + 70W
        • (8ohm,20Hz-20kHz,THD0.07%)
        • 140W + 140W
        • (4ohm, 1kHz, THD0.7%)
        Speaker Impedance
        • A or B : 4 ~ 16ohm
        • A + B : 8 ~ 16ohm
        Frequency Response
        • 5Hz - 100kHz (0~ -3dB)
        Total harmonic distortion
        • 0.01 % (Rated output: –3 dB),
        • 8 ohm/ohms, 1 kHz
        Damping Power
        • 100 and over
        Input Sensitivity: Phono input
        • MM: 2.5 mV / 47 kohm
        • MC: 200
        RIAA Deviation
        • 20 Hz - 20 kHz ±0.5 dB (MM/MC)
        Phono Maximum Input
        • MM : 130mV / 1kHz
        • MC : 10mV / 1kHz
        Input Sensitivity: CD/LINE/RECORDER
        • 125 mV / 19 kohm
        Input Sensitivity: Power Amp input
        • 0.85V / 47kohm (EXT. PRE)
        Signal to Noise Ratio
        • PHONO (MM): (89dB)
        • PHONO (MC): (74dB)
        • CD: (107dB)
        Tone Control
        • BASS : 100Hz ±8dB
        • TREBLE : 10kHz ±8dB
        Power Consumption
        • 295W
        • At Standby:
          0.2W TV autoplay off
          0.4W TV autoplay on
        Audio Feature
        • Power Amplifier Circuit: New UHC-MOS
          Single Push Pull (7)
        • Power Trans: Dual El Core
        • Pre Amplifier Circuit: Variable Gain Preamplifier (OP AMP)
        • Volume: Electric (MUSES 72323)
        • Bass / Treble / Mid / Balance Control: Yes / Yes / No / Yes
        • Type of Tone Control: Electric
          Controlled by Potentiometer
        • Headphone Circuit: Use Poweramplifier
        • Source Direct: Yes
        • Analog Amp Mode: Yes (button on front panel)
        • Other: 70
        • DAC Circuit: PCM1795
        • Digital Filter: Fixed
        • Digital Processing: Advanced AL32 Processing Plus
        • DAC Master Clock Design (Not Support Network Playback): Yes
        • Asyncronous mode (for USB-B input): yes
        • Isolator (for USB-B input): Yes Full Isolation
