About

Description

Ooberpad presents to you Fyne Audio F1.10 Floorstanding Speaker (Pair). The F1-10 distils Fyne Audio’s decades of point source loudspeaker expertise into a design of breath-taking acoustic performance and eye-watering beauty. Its 250mm (10″) IsoFlare driver and twin cavity BassTrax ported cabinet deliver bass down to 28Hz while the 75mm titanium dome compression tweeter offers seamless, time aligned HF response to over 26kHz. The F1-10’s very high sensitivity (94dB/W) ensures exceptional dynamic range and compatibility with the widest range of amplifiers from single ended triode valve models to the highest power solid state designs. The BassTrax porting and high quality potentiometer controls for HF energy and presence ensure the F1-10 will deliver optimum performance irrespective of room size or placement. Whether you choose contemporary piano black, stylish gloss white or traditional lacquered burr walnut finish with plinth top, the F1-10 offers exemplary finish and a bold statement in loudspeaker design.

Warranty

2-year manufacturer's warranty


Key Features:

  • The design is truly unique
  • Exquisite aesthetic appeal.
  • High quality gold plated WBT Nextgen ™ bi- wire terminals and Neotech ™ PC-OCC internal wiring provide highly transparent signal transfer.
  • Cryogenic treatment of the complete crossover relaxes stresses in materials and solder joints also helps maximise signal transparency

      Benefits of Fyne Audio F1.10 Floorstanding Speaker (Pair):

      Meet the F1-10

      The F1-10 is the first model in our high end F1 series. The design is truly unique and the innovative feature list is outstanding. From the massive 16kg plinth to the intricate burr walnut inlay on the front and top of the cabinet, every element of the loudspeaker has been meticulously considered to ensure stunning audio performance combined with exquisite aesthetic appeal.The first finish available will be a luxurious high gloss walnut with burr walnut inlay on the front baffle and the top of the speaker. The high density pressed birch ply with extensive internal bracing provides exceptional structural rigidity for low colouration.A heavy weight machined aluminium platform, provides exceptional stability for precise low frequency performance and resolution of fine detail and also integrates port energy to the room. Heavy duty support cones, adjustable from above enable precise levelling while machined aluminium cups provide protection for wooden floors.

      Isoflare point Source Driver

      The 10” (250mm) IsoFlareTM driver is a point source system whereby the bass/ midrange driver shares a common centre with the high-frequency unit. Providing outstanding stereo imaging even off axis, energy is radiated isotropically with constant directivity, following the flare of the driver cone. Sound is produced emanating from a single point, giving truly spherical wavefront generation. This preserves the harmonic structure of complex sounds, recreating the true acoustic soundfield. Giving total integration of energy at the crossover point, the loudspeaker is less dependent on room location.The high frequency unit features a highly rigid 3” titanium HF diaphragm for smooth and unstressed performance, with a massive Neodymium magnet incorporating a vented rear chamber to place low frequency resonance well below the crossover region. This enables a very low 750Hz crossover point giving a realistic rendition of vocals.A high power edgewound aluminium voice coil on a Kapton former utilises a copper shorting ring for low distortion. The annular waveguide has a computer optimised expansion rate and geometry to provide flat frequency response and avoid internal reflections.On the low frequency section a multi-fibre paper cone gives natural sounding midrange and clean transient behaviour. The twin roll fabric surround effectively terminates cone energy, without time-smearing. The high power LF motor system uses a ferrite magnet, with rectangular copper voice coil on aluminium former, to aid power dissipation. The complete unit is built into a rigid cast aluminium chassis to eliminate unwanted vibrations and is coupled to the internal bracing through compliant damping mastic.

      Basstrax Tractrix Diffuser System

      The F1-10 employs a downwards firing port system using twin cavity reflex loading. This loading technique broadens the tuning frequency to reduce cone excursion and acts as a muffler, blocking standing waves produced by the main internal port.Below the vent in the base of the loudspeaker, the BassTrax ™ Tractrix profile diffuser (patent applied for) is used to convert the plain wave energy to an expanding spherical 360-degree wavefront, integrating energy uniformly into the room. This makes the loudspeaker less critical of room positioning.This Tractrix profile has been previously applied to horn loudspeakers by Voight in the 1920’s, but the application to a diffuser of this type is thought to be novel. The BassTrax ™ Tractrix profile is known to maintain a 90 degree angle at each intersection of the expanding wavefront, thus avoiding reflections.

      Crossover

      The crossover uses high quality precision components, including low loss LF laminated core inductors, non- inductive thick film resistors and Claritycap highest grade HF polypropylene capacitors. The design is computer optimised, fine tuned by critical auditioning. High quality gold plated WBT Nextgen™ bi- wire terminals and Neotech ™ PC-OCC internal wiring provide highly transparent signal transfer.
      Cryogenic treatment of the complete crossover relaxes stresses in materials and solder joints also helps maximise signal transparency. The crossover is hard wired on fibre board panels to minimise vibration, while a grounding terminal prevents radio frequency interference effects from masking fine detail. Controls are provided for user adjustment of high frequency energy and presence.

      Where to buy?
      Buy Fyne Audio F1.10 Floorstanding Speaker (Pair) online at the best price in Mumbai, Delhi, Bangalore, Chennai and all across India. Enjoy expert, prompt and courteous customer service from the Ooberpad.com team. We will help you choose better and will give you all the support you need to take the right buying decision in India.


      Technical Specifications of Fyne Audio F1.10 Floorstanding Speaker (Pair):

      Brand & Model #

      Fyne Audio F1.10 Floorstanding Speaker (Pair)


      System Type

      2 way, downwards firing port with BassTrax Tractrix diffuser

      Recommended amplifier power (Watt RMS)

      20 - 280

      Continuous power handling (Watt RMS)

      140

      Sensitivity (2.83 Volt @ 1m)

      94dB
      Nominal impedance

      8 Ohm
      Frequency response (-6dB typical in room)

      28Hz - 26kHz

      Drive unit complement

      1 x 250mm IsoFlare point source driver, multi-fibre bass / midrange cone, with 75mm titanium dome compression tweeter, neodymium magnet system

      Crossover frequency

      750Hz

      Crossover type

      Bi-wired passive low loss, 2nd order low pass, 2nd order high pass, Deep Cryogenically Treated

      Dimensions - HxWxD

      1191 x 405 x 581mm (46.9 x 15.9 x 22.9”)

      Weight - Each

      72kg
      Description

      Ooberpad presents to you Fyne Audio F1.10 Floorstanding Speaker (Pair). The F1-10 distils Fyne Audio’s decades of point source loudspeaker expertise into a design of breath-taking acoustic performance and eye-watering beauty. Its 250mm (10″) IsoFlare driver and twin cavity BassTrax ported cabinet deliver bass down to 28Hz while the 75mm titanium dome compression tweeter offers seamless, time aligned HF response to over 26kHz. The F1-10’s very high sensitivity (94dB/W) ensures exceptional dynamic range and compatibility with the widest range of amplifiers from single ended triode valve models to the highest power solid state designs. The BassTrax porting and high quality potentiometer controls for HF energy and presence ensure the F1-10 will deliver optimum performance irrespective of room size or placement. Whether you choose contemporary piano black, stylish gloss white or traditional lacquered burr walnut finish with plinth top, the F1-10 offers exemplary finish and a bold statement in loudspeaker design.

      Warranty

      2-year manufacturer's warranty


      Key Features:

      • The design is truly unique
      • Exquisite aesthetic appeal.
      • High quality gold plated WBT Nextgen ™ bi- wire terminals and Neotech ™ PC-OCC internal wiring provide highly transparent signal transfer.
      • Cryogenic treatment of the complete crossover relaxes stresses in materials and solder joints also helps maximise signal transparency

          Benefits of Fyne Audio F1.10 Floorstanding Speaker (Pair):

          Meet the F1-10

          The F1-10 is the first model in our high end F1 series. The design is truly unique and the innovative feature list is outstanding. From the massive 16kg plinth to the intricate burr walnut inlay on the front and top of the cabinet, every element of the loudspeaker has been meticulously considered to ensure stunning audio performance combined with exquisite aesthetic appeal.The first finish available will be a luxurious high gloss walnut with burr walnut inlay on the front baffle and the top of the speaker. The high density pressed birch ply with extensive internal bracing provides exceptional structural rigidity for low colouration.A heavy weight machined aluminium platform, provides exceptional stability for precise low frequency performance and resolution of fine detail and also integrates port energy to the room. Heavy duty support cones, adjustable from above enable precise levelling while machined aluminium cups provide protection for wooden floors.

          Isoflare point Source Driver

          The 10” (250mm) IsoFlareTM driver is a point source system whereby the bass/ midrange driver shares a common centre with the high-frequency unit. Providing outstanding stereo imaging even off axis, energy is radiated isotropically with constant directivity, following the flare of the driver cone. Sound is produced emanating from a single point, giving truly spherical wavefront generation. This preserves the harmonic structure of complex sounds, recreating the true acoustic soundfield. Giving total integration of energy at the crossover point, the loudspeaker is less dependent on room location.The high frequency unit features a highly rigid 3” titanium HF diaphragm for smooth and unstressed performance, with a massive Neodymium magnet incorporating a vented rear chamber to place low frequency resonance well below the crossover region. This enables a very low 750Hz crossover point giving a realistic rendition of vocals.A high power edgewound aluminium voice coil on a Kapton former utilises a copper shorting ring for low distortion. The annular waveguide has a computer optimised expansion rate and geometry to provide flat frequency response and avoid internal reflections.On the low frequency section a multi-fibre paper cone gives natural sounding midrange and clean transient behaviour. The twin roll fabric surround effectively terminates cone energy, without time-smearing. The high power LF motor system uses a ferrite magnet, with rectangular copper voice coil on aluminium former, to aid power dissipation. The complete unit is built into a rigid cast aluminium chassis to eliminate unwanted vibrations and is coupled to the internal bracing through compliant damping mastic.

          Basstrax Tractrix Diffuser System

          The F1-10 employs a downwards firing port system using twin cavity reflex loading. This loading technique broadens the tuning frequency to reduce cone excursion and acts as a muffler, blocking standing waves produced by the main internal port.Below the vent in the base of the loudspeaker, the BassTrax ™ Tractrix profile diffuser (patent applied for) is used to convert the plain wave energy to an expanding spherical 360-degree wavefront, integrating energy uniformly into the room. This makes the loudspeaker less critical of room positioning.This Tractrix profile has been previously applied to horn loudspeakers by Voight in the 1920’s, but the application to a diffuser of this type is thought to be novel. The BassTrax ™ Tractrix profile is known to maintain a 90 degree angle at each intersection of the expanding wavefront, thus avoiding reflections.

          Crossover

          The crossover uses high quality precision components, including low loss LF laminated core inductors, non- inductive thick film resistors and Claritycap highest grade HF polypropylene capacitors. The design is computer optimised, fine tuned by critical auditioning. High quality gold plated WBT Nextgen™ bi- wire terminals and Neotech ™ PC-OCC internal wiring provide highly transparent signal transfer.
          Cryogenic treatment of the complete crossover relaxes stresses in materials and solder joints also helps maximise signal transparency. The crossover is hard wired on fibre board panels to minimise vibration, while a grounding terminal prevents radio frequency interference effects from masking fine detail. Controls are provided for user adjustment of high frequency energy and presence.

          Where to buy?
          Buy Fyne Audio F1.10 Floorstanding Speaker (Pair) online at the best price in Mumbai, Delhi, Bangalore, Chennai and all across India. Enjoy expert, prompt and courteous customer service from the Ooberpad.com team. We will help you choose better and will give you all the support you need to take the right buying decision in India.


          Technical Specifications of Fyne Audio F1.10 Floorstanding Speaker (Pair):

          Brand & Model #

          Fyne Audio F1.10 Floorstanding Speaker (Pair)


          System Type

          2 way, downwards firing port with BassTrax Tractrix diffuser

          Recommended amplifier power (Watt RMS)

          20 - 280

          Continuous power handling (Watt RMS)

          140

          Sensitivity (2.83 Volt @ 1m)

          94dB
          Nominal impedance

          8 Ohm
          Frequency response (-6dB typical in room)

          28Hz - 26kHz

          Drive unit complement

          1 x 250mm IsoFlare point source driver, multi-fibre bass / midrange cone, with 75mm titanium dome compression tweeter, neodymium magnet system

          Crossover frequency

          750Hz

          Crossover type

          Bi-wired passive low loss, 2nd order low pass, 2nd order high pass, Deep Cryogenically Treated

          Dimensions - HxWxD

          1191 x 405 x 581mm (46.9 x 15.9 x 22.9”)

          Weight - Each

          72kg
