Jeff Rowland Model 625 S2 Stereo Power Amplifier
Country of Origin: Usa
The Jeff Rowland Model 625 Series 2 Stereo Power Amplifier is now available on Ooberpad. It incorporates many of the same technical features as the 725 amplifiers. Similar to the 725, the 625 S2 signal circuitry is developed upon a Rogers ceramic circuit board laminate material for lower dielectric absorption and energy storage. The 4-Pole filter capacitors used in the 725 power supply have also been included in the S2, significantly reducing power supply output noise. The maximum output power has been enhanced from 300 to 325 watts per channel at 8 ohms. Precision LED based current sources have been implemented throughout the amplifier circuitry, along with 0.1% thin film SMD resistors for more stable operating points and lower noise. Custom designed Lundahl input transformers are applied with a higher turns ratio and wound with Cardas high purity copper wire.
Input circuitry comprises an additional linear phase 2 pole filter to remarkably attenuate all out-of-band signals from any source, including DSD spurious noise. Cardas gold/Teflon/rhodium XLR input connectors are carried over from the 725. Newly crafted error-correction circuitry has been included around the entire amplifier, making a total of three independent error-correction techniques used to decrease all forms of distortion throughout the entire audio bandwidth. The Model 625 S2 renders a sensuous grain-free musicality of unmatched transparency and low level resolution that blossoms from a rich velvety silence and blossoms into the most pristine enjoyment of your listening experience.
1-year manufacturer's warranty
- Machined Aluminum Chassis
- Composite Circuit Architecture
- High-Current Copper Bus-bars
- Flexible 20 Amp AC Power
- Front Panel Standby Button
- Rear Panel Remote Jack
- Removable 3-point self-leveling Delron chassis supports
Benefits of Jeff Rowland Model 625 S2 Stereo Power Amplifier:
Machined Aluminim Chassis
Precision-machined chassis with integrated heat-sinks, milled from a solid block of aircraft grade aluminum, provides exceptional thermal heat transfer/dissipation, RFI/EMI shielding, and resonance control.
Composite Circuit Architecture
Unique composite circuit architecture incorporating separate Class AB voltage and current gain blocks with no overall negative feedback, delivers a sensuous grain-free musicality of unparalleled transparency and low level resolution.
Inherent cancellation effects of balanced topology implemented throughout all power and input/output circuits ensures greatly reduced distortion and noise under dynamic signal conditions.
High-Current Copper Bus-Bars
High-current, dual polarity, ultra low impedance copper bus-bars distribute both power supply input current and signal output current, virtually eliminating intra-circuit EMI signal contamination, greatly reducing internal wiring, while increasing circuit board rigidity.
High Precision Surface Mount Components
Extensive use of Lead (Pb)-free, low temperature coefficient, active and passive surface-mount components results in significantly smaller loop areas, reduced circuit capacitance and inductance, and introduces less noise than conventional leaded components.
Transformer-Coupling and Isolation
Transformer coupled input circuitry provides universal component compatibility and virtually eliminate ground loop noise and RFI/EMI. Transformer coupling ensures identical amplifier overall gain when using unbalanced input adapters.
High-Efficiency Switch-Mode Power Supply
Highly efficient, compact, light weight, 1500 watt DC switch-mode power supply provides optimum voltage regulation for all circuits and operating conditions, and allows for quiet operation over a wide range of AC mains power sources.
Dual-Position Speaker Terminals
Dual CE approved speaker output terminals, in both horizontal and vertical orientation, require no tools for secure, low resistance connections, and allow for easy bi-wiring applications.
Buy Jeff Rowland Model 625 S2 Stereo Power Amplifier online at the best price in Mumbai, Delhi, Bangalore, Chennai, Kerala, Hyderabad and all across India. Enjoy expert, prompt and courteous customer service from the Ooberpad team. We will help you choose better and give you all the support you need to take the right buying decision in India.
Technical Specifications of Jeff Rowland Model 625 S2 Stereo Power Amplifier:
|Brand & Model #||Jeff Rowland Model 625 S2|
325 watts @ 8 ohms / 600 watts @ 4 ohms
10 Hz – 150 kHz, -3 dB
95 dB, ref. 1.0 watt @ 8 ohm load
< 100 µv, A-wtd
> 91 dB @ 1 kHz, 74 dB @ 20 kHz
|Input Impedance||40k ohms|
|THD + Noise||
< 0.001% @ 1 kHz, 8 ohms
> 200, 20 Hz – 20 kHz
|Overall Gain / Bal. or Unbal.||26 dB
|Common Mode Rejection Ratio||
> 90 dB, 20 Hz – 20 kHz
|Absolute Phase Non-inverting||
Pin 2 Positive
|Inputs||1 pair balanced (XLR)|
|Outputs||2 pair parallel binding posts per channel|
|Power Consumption Idle||100 watts|
|Power Consumption Standby||< 0.5 watt|
|Amplifier Weight||54 lbs. / 24.5 kg|
|Amplifier Dimensions (h/w/d)||
5.75” x 15.5” x 16.25” / 146mm x 394 mm x 413mm
